Supported Video Input Signal	1x SDI
Monitoring / Playback Output	1x SDI (Input Loop Thru) 1x HDMI, 1x SDI (Out)
Embedded Audio	Both In & Out (8-CH on SDI/HDMI)
Storage Medium	2.5" Hard Drive / SSD*, Max capacity 1TB
Estimated Record Time (min per 10GB)	SD: 19 (50Mbps) - 70 (8Mbps) HD: 8 (125Mbps) - 62 (10Mbps)
Recording Media	1x 2.5" Removable HDD/ SSD
Storage File System	NTFS
Video Recording Bit Rate / Color Sampling	MPEG2 Long GOP HD: 1. 10/ 25Mbps 4:2:0 1440x1080/1280x720, 2. 35/ 50/ 65/ 120Mbps 4:2:2 1920x1080/1280x720, MPEG2 Long GOP SD: 1. 8Mbps 4:2:0 720x480/720x576 (to be F/W upgrade) 2. 15/ 30/ 50Mbps 4:2:2 720x480/720x576 MPEG2 I-Frame Only HD: 1. 80/ 100/ 125Mbps 4:2:2 1920x1080/1280x720 MPEG2 I-Frame Only SD: 1. 25/ 50Mbps 4:2:2 720x480/720x576
Audio Recording Format	Uncompressed PCM Sampling rate 48KHz 24bit
External Control	RS-232/422 (Dsub 9pin), GPI (min XLR)
Country of Origin	Taiwan
Brand	Datavideo
