Range
|
30°C to 45°C (86°F to 113°F) |
|
Sensing
|
Uncooled Microbolometer |
|
Resolution
|
120x90 |
|
Deviation
|
0.3°C, Environment Temperature: 20°C ̴ 35°C (68° F ̴ 95°F), No airflolws indoor |
|
Accuracy
|
0.1°C |
|
Temperature Detection
|
0.3 to 1.2 m (0.98 to 3.94 ft) |
|
Speed
|
±100ms |
|
Display
|
7inch Display |
|
Camera
|
Dual-lens |
|
Sensor
|
1/2.8° 2MP Progressive Scan CMOS |
|
WDR
|
120db |
|
Light Compensation
|
Auto White Light, Auto IR Light |
|
Storage Capacity
|
RAM: 1 GB, EMMC: 8 GB |
|
Authentication Mode
|
Face, Body Temperature |
|
Face Recognition Distance
|
0.3 to 2.0m(0.98 to 6.56ft) |
|
Face Anti-Soofing
|
Support |
|
Audio Prompt
|
Support |
|
Face Recognition Accuracy
|
≥99.8% |
|
Face Recognition Time
|
< 0.2 s |
|
Face Image Capacity
|
30,000 |
|
Record Capacity
|
60,000 event capacity |
|
Ethernet
|
1 RJ45 10M/100M Ethernet port |
|
Alarm
|
3-ch alarm input, 1-ch alarm output |
|
Wiegand Input
|
1 (Support peripheral card reader) |
|
Wiegand Output
|
1 (WG26, WG34) |
|
USB
|
1 USB2.0 port |
|
Door Lock Output
|
1 (Switch quantity) |
|
Power Supply
|
12V 2A DC |
|
Power Consumption
|
Max 8 W |
|
Brand
|
ALTECH |
